RS-775 Motor 7000 RPM 12V comes with high torque motor having capacity to use for various drilling applications. The main application of this motor is to build low RPM; high torque DC motors which are achieved by including gear-box reduction. We can decrease a base motor RPM from 7000 to 1 just arranging extra gear-box. This motor has single bearing at front side and bush at back side.
Specifications:
- Model: RS-775
- Operating voltage (V): 4.5 – 12V
- Nominal voltage (V): 12V
- No Load speed (RPM): 7000
- No Load current (A): 0.8
- Stall Current (A): 36
- Stall Torque (g-cm): 5482
At Maximum Efficiency:
- Speed (RPM): 6070
- Current (A): 5.25
- Torque (g-cm): 725
- Output (W): 45.19
- Efficiency (%): 71.8
- Motor Diameter: 42 mm
- Motor Length: 77 mm
- Shaft Diameter: 5 mm
- Shaft Length: 16 mm
- Weight (gm): 356
Package Includes:
- 1 x RS-775 Motor 7000 RPM 12V High Torque
